    Overview

    Overview

    amina 1: Serious power. Serious value.

    Roughly the size of an outdoor electrical socket but with three times the power.

    The power you need

    amina 1 is engineered to give your car the power it needs (7.4 kW) when you charge at home. Add up to 35 km range – the average daily distance driven by EV drivers – in just 1 hour.

    Looks that are made to last

    amina 1 is made for your car but designed for your home. With its robust build, compact size, closable lid and a matte black finish, it will complement your house for years to come.

    Buy here

    Small size,
    big difference

    amina 1 keeps things neat with a compact design. It's all about doing more with less – fewer parts, less plastic, but it still charges your car safely.

    Buy here

    Up to 7,4 kW

    The sensible home charging speed. Add over 300 km range while you sleep.

    Lightweight

    At only 1 kg, it’s among the smallest EV chargers you can get.

    Compact and robust

    Closable lid for discreet looks and ultimate protection from the elements.

    Tried and tested

    5-year warranty and compliance with all relevant EU standards.

    Weather proof (IP54)

    Made to withstand any weather condition, from -35° C to +50° C.

    Vehicle to grid technology means you can power your house directly from your BEV's battery.

    Charges any car

    Type 2 charging socket is compatible with all modern EVs and hybrids.

    Minimal size

    Only 10 cm tall, 20 cm wide and 12 cm deep.

    Quick installation

    Designed and engineered in collaboration with electricians.
      amina 1 ev charger

    Simple, smart charging

    Charge smart, save money. amina 1 is designed to let you charge smarter with the apps you use every day.

    Charge smart with amina

    Check it out

    amina 1 is the ultimate combination of quality, simplicity and affordability. It’s the smart choice for people who want to recharge their car from the comfort and convenience of their house – or vacation home.

    Buy amina 1

    Specs

    Technical specifications

    1. Dimensions

      Height 125 mm
      Width 200 mm
      Depth 105 mm

      Max current & charging output

      Current: 6-32 A, 1-phase
      Output: 1,3 – 7,4 kW

      Weight

      1,15 kg

      Electrical protection

      Protection class II (4 kV AC and 6 kV impulse, insulation)
      Overvoltage category III (4 kV)

      Degree of protection

      Resistant to impact, dust, water IP54: indoor and outdoor use IK08: impact protection
UL94: flammability rating
UV-resistant

      Color

      Black

      Charging socket

      Type 2 – IEC 62196-2

      Surface

      Matt

    2. Standards and approvals

      CE-compliant according to IEC 61851- 1:2017, IEC 62955 and ROHS-directive 2011/65/EU

    3. Box content

      – Backplate
      – Charge unit
      – Front cover
      – Installation kit

      Required for installation

      – TX20 screwdriver
      – Circuit breaker
      – External RCD Type A

    Documentation

    Downloads

    Click on the button below to find updated documentation for amina 1 in several languages, such as:

    – Quick guide
    – Product sheet
    – Warranty
    – Declaration of conformity
    Downloads

    FAQ

    Any questions?

    FAQ

    These are the five most frequently asked questions (FAQ) about amina 1. If you need further assistance, get in touch or check out the full FAQ page.
    Contact FAQ

    Click on the “find dealer” button to see all partners and resellers and what they currently sell it for.

    7.4 kW – this corresponds to over 35 km range per hour charged.

    amina 1 charges your car in all kinds of weather, from -30° C to +40° C.

    You can charge all cars with a type 2 connector, the European standard.

    If your car can time-control the charging, you can either do it directly from the car, via the car’s app, via a smart charging app or via your electricity company.

    Yes. The amina charging app lets you update the software on your amina S and check its basic status. The app connects to the charger over Bluetooth, so stand near the charger when you use it. amina 1 has no connectivity and does not use the app.

    Get amina charging on the App Store or Google Play.

    The vehicle controls the connector lock, not the charger. On every amina model the release comes from the car side, so that is where to start.

    1. End the charging session in your car or in your car’s app.
    2. Unlock the car fully with the key or app. Some cars need a separate “unlock charging cable” action in the EV settings menu, not just a door unlock.
    3. Pull the connector straight out, firmly, without forcing it.
    4. If it still will not release, switch the charger’s circuit breaker off, wait ten seconds, switch it back on, and try again.

    amina 1 uses a Type 2 socket and your own cable, so the connector can be held at either end. The same steps apply.

    If the cable is still held after a power cycle, stop pulling and get in touch. Forcing it risks damaging the connector or the socket.

    amina S, amina C and amina M ship with a 6 m Type 2 cable, factory fitted. If the cable is damaged, an electrician can replace it using the official replacement part.

    A 9 m cable is available for B2B customers to order and offer to their own customers. amina does not sell the 9 m cable directly to consumers. Contact the business that supplied your charger to ask whether it is available.

    amina 1 is different. It has a Type 2 socket and no cable included, so you can use any Type 2 cable rated for your charging current, at whatever length suits you.

    amina M. It has an RJ45 Ethernet port alongside 4G and Wi-Fi, which makes it the most reliable choice wherever a cable run is possible.

    The others do not:

    • amina C has 4G LTE and dual-band Wi-Fi, but no Ethernet.
    • amina S has Bluetooth and Zigbee only.
    • amina 1 has no connectivity at all.

    Yes, but how depends on the model.

    • amina M has no built-in load balancing. It works with an external energy meter, through a local or a cloud solution.
      • Local: amina tested and supports the Xemex module. The module connects to amina M over Modbus RTU. It reads data from the P1 port of the smart meter or from CT clamps. The installer sets the main fuse size on the charger. amina M then adjusts its charging current to stay within that limit.
      • Cloud: A Chargee Sparky, a Chargee Flint or a Saveeye+ device can manage load balancing through your charging platform (CPMS). This works only if your CPMS has an integration with the device and controls the charger over OCPP.
    • amina C gets load balancing from your CPMS through OCPP smart charging profiles.
    • amina S gets load balancing from a third-party Zigbee hub, for example EVA Smart, Perific, Homey or Home Assistant. amina S has no charger-to-charger load balancing.
    • amina 1 has no connectivity, so instead a fixed maximum current is set on the dial by your electrician at installation.

    amina chargers are built for the European market. They use the Type 2 connector and are designed for European electrical systems and standards.

    amina chargers are currently live in Norway, Sweden, Finland, Denmark, the Netherlands, Germany, Switzerland, Austria, Italy, Spain, the Baltic states, Poland, Iceland and Ireland.

    Availability and sales routes vary by country. For these markets, or to discuss another market, contact sales through aminacharging.com/contact. Arrangements may be possible outside the countries listed.

    Use the contact form at aminacharging.com/contact for product support, technical questions or help with an existing charger. Your enquiry will be sent to the right team.

    amina does not publish a general support phone number. Include your charger model, country, installer or dealer, and a short description of the issue so the team can respond efficiently.
